Shrink Tunnel
Model: PPD-4525
Shrink film: POF film
Tunnel dimensions (L×W×H): 1200×450×250mm
Product size: 400×200mm
Feed speed: 0-15m/min
Conveyer: roller chain conveyor
Max. conveyor load: 25kg
Machine dimensions (L×W×H): 1600×700×1520mm
Machine weight: 185kg
Power supply: 380V 50-60Hz
Power: 12kW
- Control panel uses programming system, 12V DC input, button switch and digital display;
- 3P circuit breaker is equipped to protect electrical devices, air volume can be flexibly adjusted by air flow control;
- Height adjustable bracket can be disassembled to accommodate to changing work environments;
- High temperature and wind resistant fabric is adopted to prevent operators form overheating while avoiding the risk of dirt or dust entering;
- Stainless steel guide rails reduce the abrasion of silicone rubber;
- Infrared quartz heating tube offers more stable heating effect;
